Avant

The One and Only

Avant

An innovation by Roca, unique in the world

Roca has reimagined the bathroom space by introducing a cutting-edge toilet with integrated cistern that frees up valuable space. Available in two versions to suit different installations: Avant, for a mains pressure of at least 2 bar and a flow rate of at least 14 litres per minute, and Avant-E, with an electrical connection, for lower pressure or flow. A step into the future with simplified bathroom routine.

...

You've seen 8 of 12 images

Main features

All in one solution. All in one piece.

Avant integrates the cistern inside the bowl, out of sight. This frees up space in the bathroom and unifies aesthetics and practicality in the bathroom. No visible operating plate disrupts the clean lines, creating an airy feel.

All components are easily accessible and easy to handle, particularly those related to water function, which are positioned off the walls. The cistern is easy to access for straightforward installation and maintenance, avoiding the need to modify the wall during major repairs. Moreover, Avant incorporates a seal-free flushing system: there are no seals between the cistern and the bowl, which removes these potential leak points.

Perfect aesthetics, simple control.

Less is more in the Avant innovative toilet: Designed with a neutral and contemporary aesthetic to match any bathroom space.

Easy flushing control: the integrated cistern features a dual-flush mechanism, with 4.5/3 L flushes to choose from, using mains water pressure at 2.0 bar and a flow rate of 14 litres per minute.

A WC that comes in two models: One wall-hung and other back to wall floorstanding. Both offer a modern touch and create a more visually spacious and airy environment. The WC complies with European regulations, including EN1717, ensuring security standards.

Science making life easier. The system explained

01

When the tank reaches full capacity, the flush mechanism float is in the initial position, and the flush mechanism is in the closed state.

02

Once the flush button is pushed, the float is released from the mechanism and floats. The mechanism opens and the water enters from the net producing the Venturi effect which allows a water of the tank suction. While it flushes, the water level drops, and the float is still floating.

03

This suction effect runs while the water coming from the mains still enters, producing the Venturi effect. Until the water level in the tank doesn’t reach the float initial position, the flushing continues.

04

Finally, the water level drops to the point that the float returns to the initial position; it is where is retained and the mechanism closes the water inlet. The tank is filled again through the filling mechanism.

Integrated cistern (with or without electrical connection)

The cistern is incorporated inside the bowl, out of sight. This maximizes available space and provides a modern and pleasing aesthetic. With or without electrical connection, Avant is compatible with most existing installations and requires a minimum water pressure of 2 bar and a flow rate of 14 litres per minute.

Venturi effect

The Venturi effect creates a powerful suction force, ensuring superior flushing for a thorough and hygienic clean.

Roca Rimless^® Vortex

A bowl specially designed to optimize water flow, flush performance and cleaning. No splashing and aerosols reduction.

Silent solution

Reducing the noise for a more comfortable user experience.

Supraglaze^®

Smooth glazed surface that is easy to clean.

Easy control by side panel

Thanks to its discreet and intuitive flush controls, the toilet offers a user-friendly experience. Two flush volumes to choose from: 4.5 or 3 litres.

Seal-free solution

All flushing systems are integrated into the toilet and are seal-free, providing extra safety.

Easy installation & Easy maintenance

Designed for effortless installation and maintenance, ensuring a hassle-free experience in any bathroom space and prevents leakage.

Quick Release & Soft Close Seat and Cover

It provides a stable and comfortable seating experience and gently closes with a whisper-quiet click. The seat and cover are easily removable, making the task of cleaning simpler.

Product range

Avant

Avant-E - Wall-hung WC with integrated In-Tank® cistern

Ref: A80336NS01

565 x 385 x 475

Avant

Avant - Wall-hung WC with integrated In-Tank® cistern

Ref: A80336NS0H

565 x 385 x 475

Avant

Avant-E - FS Back-to-wall floorstanding WC with integrated In-Tank® cistern. Internal connection

Ref: A80336MS00

565 x 385 x 475

Avant

Avant-E - Back-to-wall floorstanding WC with integrated In-Tank® cistern. External connection

Ref: A80336MS01

565 x 385 x 475

Avant

Avant - Back-to-wall floorstanding WC with integrated In-Tank® cistern. External connection

Ref: A80336MS0H

565 x 385 x 475

Avant

Avant - Back-to-wall floorstanding WC with integrated In-Tank® cistern. Internal connection

Ref: A80336MS0W

565 x 385 x 475

Avant product brochure

Download or view online Avant brochure to see more technical details.

Download / View online

Avant In-Tank^® AWARDS

iF Design Awards 2024

Roca won an iF Design Award, a world-renowned design prize with a 132-member jury made up of independent experts from all over the world, for its Avant In-Tank^®.

Red Dot Design Award 2024

Avant In-Tank^® toilet has been awarded with a Red Dot Award, a world-renowned design prize, evaluating the quality and innovation of designers and manufacturers in the creation of new products.

"Best of Best" ICONIC Award: Innovative interior" 2024

Avant In-Tank^® toilet has been awarded with a "Best of Best" ICONIC Award: Innovative interior", a world-renowned design prize organized by the German Design Council.
